Kepler NEXUS (-15) Central Heat Pump

Product Overview

Kepler products are engineered for the Canadian climate, prioritizing your comfort and well-being. A Central-Kepler heat pump system ensures a tranquil home environment, providing year-round warmth and cooling with whisper-quiet, energy-efficient performance. Whisper-Silent Operation Experience the ultra-quiet performance of our heat pump, thoughtfully designed to enhance home comfort with minimal noise disturbance.

Specification

AHR6F – 24k BTU Heat Pump System Specifications

Capacity: 24,000 BTU/hr

Indoor Unit Model: AZP/NB24WAC

Outdoor Unit Model: AZP/N5/24RCO

Power Supply (Outdoor)
Voltage / Phase / Frequency: 208–230V, 1Ph, 60Hz

Cooling (Standard Conditions)
Capacity (Range): 24,000 BTU/hr (9,800–32,200)
Input Power: 2400 W (880–2930)
Current: 9.0 A (3.0–12.0)
EER2: 10.0 Btu/hr/W
SEER2: 15.7 Btu/hr/W

Heating (Standard Conditions)
Capacity (Range): 25,600 BTU/hr (7,600–31,000)
Input Power: 2246 W (610–3000)
Current: 8.2 A (2.0–12.0)
COP: 3.34 W/W
HSPF4: 9.8
HSPF5: 8.0

Heating (H42) at 5°F (−15°C)
Rated Capacity: 18,600 BTU/hr
COP: 2.20 W/W
Capacity Ratio: 72.27%

Throttle Type
Cooling: TXV
Heating: EEV

Indoor Unit
Dimensions (W×D×H) in: 17.52 × 13.08 × 17.99
Net/Gross Weight (kg): 13.4 / 15.2

Outdoor Unit
Minimum Circuit Ampacity (MCA): 19 A
Max Fuse: 30 A
Outdoor Noise Level: 61.5 dB(A)
Dimensions (W×D×H) in: 35.04 × 13.46 × 26.50

Refrigerant Type: R410A
